Stanley 603All position chromium carbide electrode for abrasion and medium impact
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
All position chromium carbide electrode for abrasion and medium impact
- Thinner than normal coating allows for ease of use out of position.
- Molten metal is viscous and easy to control.
- Slag is self releasing.
|
|
Overview |
|
Specifications |
|
Email to a Friend |
|
APPLICATIONS:
For general overlaying on construction and mining equipment.
MICROSTRUCTURE:
Austenitic alloy matrix and chromium complex carbides.
FLUX COLOR: Dark Grey
TYPICAL MECHANICAL PROPERTIES:
Undiluted Weld Metal
H a r d n e s s
Wear Co-efficient |
Maximum Value Up to:
Brinell 600, Rockwell C57-59
1.9% |
RECOMMENDED CURRENT: AC/DC (+)
RECOMMENDED AMPERAGE SETTINGS:
| Diameter (mm) |
1/8(3.25) |
5/32 (4.0) |
3/16 (5.0) |
| Minimum Amperage |
90 |
140 |
180 |
| Maximum Amperage |
120 |
170 |
220 |
WELDING POSITIONS: Flat, Vertical up, Horizontal, Overhead
DEPOSITION RATES:
Diameter
(mm) |
Length
(mm) |
Weldmetal/
Electrode |
Electrodes per lb
(kg) of Weldmetal |
Arc Time of
Deposition
min/lb (kg) |
Amperage
Setting |
Recovery
Rate |
| 1/8 (3.25) |
14" (350) |
.8oz (25g) |
17 (37) |
28 (62) |
105 |
135% |
| 5/32 (4.0) |
14" (350) |
2.2oz (61g) |
8 (17) |
21 (46) |
155 |
135% |
| 3/16 (5.0) |
14" (350) |
3.2oz (90g) |
6 (13) |
16 (35) |
200 |
135% |
WELDING TECHNIQUES:
Lay down either stringer or weave beads at low amperages.
ELECTRODE PACKAGING & DIMENSIONS:
| Diameter(mm) |
1/8 (3.25) |
5/32 (4.0) |
3/16 (5.0) |
| Length (mm) |
14" (350) |
14" (350) |
14" (350) |
| Electrodes / lb |
11 |
8 |
6 |
| Electrodes / kg |
24 |
17 |
13 |
|
|
