Stanley 605Large Diameter, Low amperage tubular hardfacing electrode
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
Large diameter-low amperage tubular hardfacing electrode
- Thin walled tubular construction allows for very low amperages.
- Base metal dilution is negligible and maximum hardness is achieved rapidly.
- Quickest non-automated overlaying technique.
- Special bendable aluminum grip end caps allow for easy gripping and positioning of the electrode.
|
|
Overview |
|
Specifications |
|
Email to a Friend |
|
APPLICATIONS:
General wear protection on all iron base parts subject to abrasion.
MICROSTRUCTURE:
In the as-welded condition, the microstructure consists of an austenitic alloy matrix (bulk hardness RC57) and chromium/complex carbides (hardness RA 77).
FLUX COLOR: Dark Brown
TYPICAL MECHANICAL PROPERTIES:
Undiluted Weld Metal
H a r d n e s s
Wear Co-efficient |
Maximum Value Up to:
Rockwell C 57 - 60
Vickers 665-700
2% |
RECOMMENDED CURRENT: DC Reverse (+) or AC
RECOMMENDED AMPERAGE SETTINGS:
| Diameter (mm) |
1/4(6.5) |
5/32 (4.0) |
3/16 (5.0) |
| Minimum Amperage |
80 |
130 |
180 |
| Maximum Amperage |
125 |
200 |
380 |
WELDING POSITIONS: Flat, Vertical up, Horizontal, Overhead
DEPOSITION RATES:
Diameter
(mm) |
Length
(mm) |
Weldmetal/
Electrode |
Electrodes per lb
(kg) of Weldmetal |
Arc Time of
Deposition
min/lb (kg) |
Amperage
Setting |
| 1/4 (6.5) |
18" (450) |
3.1oz (87g) |
5 (11) |
13 (29) |
100 |
| 3/8 (9.75)) |
18" (450) |
4.4oz (128g) |
3.5 (8) |
10 (22) |
175 |
| 1/2 (13.0) |
18" (450) |
6.3oz (176g) |
2.5( 5.5) |
8 (18) |
215 |
WELDING TECHNIQUES:
Using lowest possible amps, and while holding the electrode 10o from the vertical position, deposit either stringer or weave beads.
ELECTRODE PACKAGING & DIMENSIONS:
| Diameter(mm) |
1/4(6.5) |
3/8(9.75) |
1/2 (13.0) |
| Length (mm) |
18" (450) |
18" (450) |
18" (450) |
| Electrodes / lb |
5 |
4 |
3 |
| Electrodes / kg |
11 |
9 |
7 |
|
|
