For protecting most iron base surfaces against severe abrasive wear and moderate impact.
Overview
Specifications
Email to a Friend
Chromium carbide electrode for economical smooth overlays
• Ripple free surface doubles "grip resistance" to fine abrasive media.
• 3/32(2.5mm) and 1/8(3.2mm) provide position capability.
• Special formula totally eliminates the "Worm Tracking" type porosity common to this alloy group.
• Also available as a special tubular MIG wire as product code STANLEY 651 MIG WIRE.
Overview
Specifications
Email to a Friend
TYPICAL MECHANICAL PROPERTIES :
Undiluted Weld Metal Maximum Value up to :
Hardness Rockwell C58-62
Vickers 670-700
Wear Co-efficient 2 %
APPLICATIONS :
For protecting most iron base surfaces against severe abrasive wear and moderate impact.
MICROSTRUCTURE :
In the as-welded condition, the microstructure consists of an austenitic alloy matrix (bulk hardness RC57) and chromium/complex carbides (hardness RA 77).
RECOMMENDED CURRENT :
DC reverse ( + ) or AC
WELDING POSITIONS :
Flat, Horizontal (smaller diameters can be used out of position)
WELDING TECHNIQUES :
Use a stringer or wide weave technique. Deposit a maximum of 2 to 3 passes to achieve full hardness.
