Stanley 189For repair and reclamation of tools and dies subject to heat checking.
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
Tungsten free hot work tool steel electrode
• Deposits maintain a very sharp edge.
• Alloying elements include molybdenum and vanadium.
• Weld metal maintains many of the properties of H13 tool steel.
• Also available in TIG form as product code STANLEY 169 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
TYPICAL MECHANICAL PROPERTIES :
Undiluted Weld Metal Maximum Value up to :
Hardness (as welded) Rockwell C 54-57
APPLICATIONS :
For repair and reclamation of tools and dies subject to heat checking.
MICROSTRUCTURE :
In the as-welded condition, the microstructure consists of partially tempered martensite with carbides and some retained austenite.
RECOMMENDED CURRENT :
DC Reverse (+), Straight (-) or AC
WELDING POSITIONS :
Flat, Horizontal, Vertical up.
WELDING TECHNIQUES :
When welding on tool steel, preheat the part to 1100ºF (600ºC) and maintain this temperature during welding. Allow parts to cool slowly. |
|
